Standard Features
- Kidney shaped material pusher is made from mold cast food grade aluminum
- Powerful 1/2 HP gear-driven motor
- Optimum plate speed of 336 RPMs
- Polished food grade cast aluminum construction & sealed upper housing
- Double safety interlock - hopper head and food pusher
- Ergonomic 45° food hopper incline
- Removable hopper head and food pusher (no tools required)
- Discs are antimicrobial durable composite fiberglass & dishwasher safe
- Stainless steel knives are hardened, ground, leathered and hand-polished
- 47 discs are available
Capacity
Processes up to 600 lbs. per hour. Ideal for up to 300-400 meals.
Motor
1/2 HP, 115V-60HZ-1 Phase, 3 amps, automatic reset thermal overload protection.
On/Off Latch (interlocks)
The hopper latch serves as the on/off switch and interlock for the hopper head. The unit will not operate with the hopper head open or unlatched.
Gear Drive
Sealed planetary gear transmission with permanent grease lubrication. Output 336 RPMs.
Unit Comparisons
|
GSM 4 |
GSM 5 Star |
XL, XL Star, & MultiCut-240 |
| HP |
1/2 |
1/2 |
1 |
| RPMs |
340 |
340 |
280 |
| Upper Housing |
Cast Aluminum |
Stainless Steel |
Cast Aluminum |
| Blades Available |
47 |
52 |
42,44,42 |
| Antimicrobial Protection Pusher |
|
X |
X |
| Antimicrobial Protection Blades |
X |
X |
|
Cord and Plug
Attached six-foot flexible 3-wire cord and plug fits a grounded receptacle.
Construction
The housing, removable hinged hopper head, food hoppers, removable food pusher and ejector plate are made of polished cast aluminum.
There are 47 cutting discs available. The discs are antimicrobial durable composite fiberglass. The knives are hardened, ground, leathered and hand-polished to a razor sharp edge for precision cutting and long life.
Design
Ergonomic 45° incline for convenient feeding, cutting and ejection of food. Separate food hopper permits continuous cutting of long products. The food pusher enables even pressure to be applied when cutting food. The hopper head, food pusher and cutting discs are easily removable, without the use of tools, for quick cleaning.
Warranty
Two years parts and labor.
