Elite Beverage Counter Unit
| Model # | Description | Length | Width | Height | Ship Wt.(lbs) |
|---|---|---|---|---|---|
| 2-CU | 32" | 32" | 28" | 36" | 225 |
| 3-CU | 46" | 46" | 28" | 36" | 265 |
| 4-CU | 60" | 60" | 28" | 36" | 305 |
| 5-CU | 74" | 74" | 28" | 36" | 345 |
| 6-CU | 88" | 88" | 28" | 36" | 385 |
The Elite 500 Beverage Counter Stand will accommodate a number of dispensers. The versatile modular design allows you to custom design your line-up, choosing only the options and accessories that you want and need. Elite 500 units are compatible and will interlock with other Elite 500 units. This allows the units to be disconnected for cleaning under the serving line.
STANDARD FEATURES
- 14-gauge stainless steel top with 1-1/2” turndown on all sides
- Top secured by four recessed bolts
- 14-gauge stainless steel legs
- 18-gauge stainless steel bottom shelf
- 20-gauge stainless steel end and front panels are attached to legs
- Top is furnished with 1” deep drain trough and grate fitted with a 1/2” drain valve
- Open control side for additional storage capacity
- 5” diameter swivel plate casters, 2 with brakes
- Interlocking mechanism is provided to interlock with other Elite 500 units
COMMON OPTIONS
- Tray slides
- Hinged or sliding doors
- Reinforced Top
- See reverse side for additional options.
WARRANTY
One year parts and labor. Warranty is detailed on inside front cover of the price list.
AVAILABLE OPTIONS
| Model # | Description |
|---|---|
| 3BTS | 3-Bar Tray Slide 12.75" wide w/hinged brackets |
| CUT | Cut out for drop in dispensers |
| DOUT | Duplex Outlet (120V, 15 AMP) |
| FRMA | Formica Laminate Without Doors |
| HD | Hinged doors with solid bottom |
| INT | Intermediate shelf |
| MBS | 18" maple end bread shelf; left, right - flush with top |
| MCB | Cutting Board Maple - 8" wide w/hinged brackets |
| PPC | Pizzazz Powder Coating |
| RUS | Removable bottom |
| SBS | 18" stainless steel end bread shelf; left, right - flush with top |
| SCB | Cutting Board Stainless - 8" wide w/hinged brackets |
| SD | Sliding doors with solid bottom |
| SKR | Skirting |
| SRTS | Solid 3-ribbed tray slide, 16-gauge stainless steel |
| SSL | Legs in lieu of casters |
